286.20 Pressure Intensifier 18
Specifications and Dimensions
Introduction
Specifications and Dimensions
The following tables list the dimensions, weights, and specifications for the
Model 286.20 Confining Pressure Intensifier.
Dimensions and Weights
P ARAMETER A LL M ODELS
Height 1825 mm (72 in.)
Width 600 mm (23.6 in.)
Depth 845 mm (33.3 in.)
Weight 454 kg (1000 lb.)
Reservoir Capacity 11.4 liters (3.0 gallon)
P ARAMETER M ODEL 286.20-08 M ODEL 286.20-10
Maximum Output
Pressure, MPa/PSI
Output Volume
cu. cm/in.
80/12,000
655/40
140/20,000
980/60
Recommended
Fluids Refined mineral oil (i.e., PG1¨, or Multitherm¨) or
Silicone oil for triaxial testing to +200
°
C/400
°
F
Maximum Fluid
Temperature
75
°
C (165
°
F)
Note Many triaxial cells are capable of heating
confining fluid to a temperature exceeding
this value. Therefore, it is imperative that the
fluid be allowed to cool to 75
°
C/165
°
F, or
less, before recirculating it into the Pressure
Intensifier.
Air Driven Pump
Compressed Air
Requirement 0.6 MPa (90 psi), clean and dry
