MTS Series 322 Load Frame Lifting and Moving - Manual (Page 10)

Load Unit Rating 250 kN (55 kip) 271 N·m (200 lbf·ft)
Load Unit Rating 500 kN (110 kip) 271 N·m (200 lbf·ft)
2. Make sure the crosshead’s lifting eyes are tight.
3. Cut the straps that tie the crosshead assembly to the platen.
4. Attach the lifting straps to the lifting eyes. Slowly and carefully bring the assembly to an upright position.
Description Item
Attach straps 1
Raise 2
10 Series 322 Load Frame Lifting and Moving
Lift and Move
