Bowers & Wilkins CT700 SERIES CT7.4 LCRS - Manual (Page 45)

42
CT7.3 LCRS
Technical features
Description
Drive units
Frequency range
Frequency response
Dispersion
Sensitivity
Harmonic distortion
Nominal impedance
Crossover frequencies
Recommended amplifier power
Max. recommended cable impedance
Dimensions
Net weight
Nautilus ™ tube-loaded tweeter
Kevlar ® brand fibre cone FST ™ midrange
Paper/Kevlar ® brand cone bass driver
Flowport ™
Magnetically attached grille
3-way vented-box system
1x ø25mm (1 in) cloth dome high-frequency
1x ø150mm (6 in) woven blue Kevlar ® FST ™ midrange
2x ø200mm (8 in) paper/Kevlar ® bass units
-6dB at 38Hz and 33kHz
49Hz - 28kHz ±3dB on reference axis
Within 2dB of reference response
Horizontal: over 60° arc
Vertical: over 10° arc
94dB spl (2.83V, 1m)
2nd and 3rd harmonics (90dB, 1m)
<1% 50Hz - 20kHz
8Ω (minimum 3.0Ω)
350Hz, 4kHz
50W - 200W into 8 Ω on unclipped programme
0.1Ω
Height: 360mm (14.2 in)
Width: 606mm (23.9 in)
Depth: 265mm (10.5 in) (including grille and terminals)
Depth with grille: 288mm (11.3 in)
22.5kg (49.5 lb)
