MTS Nut Grips User Manual
Page 25
MTS Fundamental™ Bolt Grips and Nut Grips
Operation
25
Debris can be discharged as a result of testing.
Debris can cause injury to personnel and damage to equipment.
Be sure to close the protection plates of the fixture and clear the personnel in front
of the fixture before testing.
Figure 11 Wedge Load Test
WARNING
Upper Protection Plate
Lower Protection Plate
Spec Mark
C
ALLOUT
D
ESCRIPTION
1
Wedge Loading Plate (M5–M10)
2
Specimen (M5–M10)
3
Threaded Adapter (M5–M10)
4
Wedge Loading Plate (M12–M30)
5
Threaded Adapter (M12–M30)
