MTS Nut Grips User Manual
Page 22
MTS Fundamental™ Bolt Grips and Nut Grips
22
Operation
The test can not be performed with the wrong loading plates and threaded
adapter.
Be sure to choose the appropriate loading plates and threaded adapters for the
specimen.
Figure 7 Proof Load Test (M5–M10)
C
ALLOUT
D
ESCRIPTION
1
Flat Loading Plate(M5–M10)
2
Specimen
3
Threaded Adapter (M5-M10)
4
Spec Mark
5
Lower Protection Plate
6
Upper Protection Plate
1
2
3
4
5
6
