Erasing the receiver's memory, Reprogramming the wireless foot pedal or remote, Foot pedal battery replacement – MotorGuide Wireless User Manual
Page 30

Section 6 - Owner Service Assistance
Page 26
90-8M4002601
eng
JUNE 2010
Handheld remote
a -
Left arrow button
b -
"+" button ‑ faster
c -
Right arrow button
d -
"–" button ‑ slower
Erasing the Receiver's Memory
Erasing the receiver's memory will erase all electronic ID numbers that are stored in the receiver's memory.
1. Plug in the battery cable to a power source. In less than ten seconds, press the left arrow, right arrow, "+" and "–" buttons on
the remote simultaneously. For foot pedals, press the "LEFT," "RIGHT," "+," and "–" buttons simultaneously.
2. Listen for a long beep indicating the receiver has erased all stored electronic ID numbers.
NOTE: If all four buttons on the remote are not pressed simultaneously within ten seconds, or a long beep is not heard, unplug
the battery cables from the power source and then refer to Section 3 - Activating the Wireless Foot Pedal or Handheld
Remote
.
Reprogramming the Wireless Foot Pedal or Remote
NOTE: This activation procedure applies to the foot pedal and remote.
IMPORTANT: To activate multiple foot pedals or remotes, the motor must be unplugged from the power source and then plugged
back into the power source between activating each control device.
1. Unplug the battery cables from the power source. Wait 30 seconds and then plug the motor into the power source.
2. In less than ten seconds, press and hold the "+" and "–" buttons on either the handheld remote or the foot pedal controller
simultaneously.
Foot Pedal Battery Replacement
Battery required: 3V lithium, CR2032
1. Remove the five screws on the battery cover plate. Remove the battery cover plate.
a -
Battery cover plate screws
b -
Battery cover plate
a
b
d
c
44737
a
a
b
44738
