193 SERIES CONCRETE MIXER DECAL LOCATIONS
Mixer Dimensions and Decal Locations
HEIGHT
67”
MIXER SPECIFICATIONS & DECAL LOCATIONS
LENGTH
45”
WIDTH
62”
Decals: A, B & C
Decals Inside: A, G, H, I, J, K, L, M & N
Decals: A & F
Decals: D & E
Decal
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Location
Description
Dump Gear Guard, Motor Side Warning Read Manual Before Operating Equipment
and Inside Motor Cabinet
Dump Gear Guard
Caution Guards in Place
Dump Gear Guard
Warning Keep Hands and Arms Out of Tub
Front Leg
Caution Fasten Safety Chain Before Towing
Front Leg
Warning Maintain Tire Pressure
Motor Side
Danger Use in Ventilated Areas
Inside Motor Cabinet
Warning Silica Dust Hazard
Inside Motor Cabinet
Danger Exhaust Contains Hazardous Chemicals
Inside Motor Cabinet
Service or Warranty Information
Inside Motor Cabinet
Warning Stop and Cool Before Refueling
Inside Motor Cabinet
Caution Do Not Touch Hot Surface
Inside Motor Cabinet
Notice Do Not Overtension Belts
Inside Motor Cabinet
Caution Keep Hands and Arm from Belt Drive
Inside Motor Cabinet
Caution Accidental Start Hazard
