Manta core drill iii parts list – MK Diamond MK-MANTA III User Manual
Page 27
27
Item
Description
Qty
Part #
BA3
Cap, Push ½” Stainless Steel
2
157435
BA4
Collar, ½ I.D. x 1” O.D. x 7/16
2
157518
BA5
Screw, ¼-20 x ¾ Flat Head Socket
4
154657
BA6
Knob, Knurled Head ¼-20 x 2 ½
1
157436
BA7
Pad, Toggle ¼-20
1
157437
C
Assembly, Telescoping Support
n/a
C1
Tube, Telescoping Support
1
158340
C2
Rod, Telescoping Support
1
158341
C3
Clovis Pin
∅
1/4 x 1 ¼
1
158452
C4
Clovis Pin
∅
1/4 x 1 5/8
1
158453
C5
Pin, Cotter 1/16 x 5/8
2
158451
C6
Knob, Tri Plastic, 5/16-18 x ¾
1
158456
C7
Bracket, Telescoping Rod Support
1
158342
C8
Nut, M22 x 1.5
1
158455
C9
Washer, M22 Flat
1
158454
D
Assembly, Carriage 2 ½”
1
n/a
D1
Body, Carriage
1
155757
D2
Shaft, Gear, Short
1
158348
D3
Bearing
2
137711
D4
Plate, Adjustment
3
157317
D5
Slide, Carriage
8
157318
D6
Screw, 6-32 x 1/2 Flat Head Phillips Machine
8
154448
D7
Screw, 6-32 x 3/8 Flat Head Phillips Machine
8
157521
D8
Nut, 6-32 Nylok Hex
8
157519
D9
Knob, Davies ¼-20 x ¾
1
151681
D10
Washer, ¼ SAE Flat
1
151915
D11
Back, Carriage
1
157438
D12
Screw, 1/4-20 X 1 Socket Head Cap
4
151049
D13
Screw, ¼-20 x 5/16 Socket Head Set
6
154226
D14
Handle, Carriage
1
157440
D15
Screw, 1/4-20 X ¾ Pan Head Phillips
2
157523
D16
Label, MK USA
2
154334
D17
Screw, 1/4-20 X 1 ¼ Socket Head Cap
4
159336
E
Assembly, Control Box, Fixed, Dual Switch 120V
1
158428
E1
Box, Fixed Dual Switch Control
1
158274
E2
Cover, Fixed Dual Switch Control Box
1
158276
E3
Screw, ¼-20 x ¾ Socket Head Cap
2
152587
E4
Washer, ¼ Split Lock
2
152591
E5
Screw, 10-24 x 5/8 Self Tapping
6
153681
E6
Ammeter 120V
1
154489
E7
Switch, 30A Toggle
2
154491
E8
Receptacle, Flanged 15A / 125V
1
154473
E9
Cord, Power SOWA 12/3 Yellow
3’
154494
E10
Connector, Cord ½
1
151307
E11
Receptacle, Flanged Twist-lock 20A / 125V
1
157375
E12
Transformer, Current 120 V AC
1
154490
E13
Screw, 6-32 x ½ Pan Head
2
153459
E14
Plug, Twist-lock, 125V / 20A
1
154556
E15
Wire Harness (not shown)
1
154715
E17
Cover, Toggle Switch
2
154301
EB
Assembly, Control Box, Single Switch 120V
1
158430
EB1
Box, Single Switch Control
1
158385
MANTA CORE DRILL III
PARTS LIST
