Page 21
21
Item
Description
Part #
Qty
GB
Assembly, 5hp Electric Motor
-
GB1
Motor, 5 hp 230v 60hz 1ph, Electric C’ face (Lesson / Baldor)
160107
1
GB2
Pulley, 2BK34X 1 1/8
160108
1
GB3
Key, Square, 1/4 x 1/4 x 1 3/4”
150796
1
GB4
Mount, Engine
157071
1
GB5
Screw, 1/2-13 x 1 1/4 UNC Hex Head
153532
4
GB6
Washer, 1/2 Split Lock
153524
4
GB7
Screw, 3/8-16 x 1” Carriage Bolt
157644
4
GB8
Washer, 3/8 SAE Flat
150923
4
GB9
Washer, 3/8 Split Lock
150925
4
GB10 Nut, 3/8-16 Hex
101188
4
GB11 Washer, 5/16 Split Lock
151747
5
GB12 Nut, 5/16-18 Hex
101196
3
GB13 Bolt, 5/16-18 x 2 ¾” Hex Head Tap
156974
1
GB14 Bracket, Switchbox (previous #227269)
160110
1
GB15 Screw, 1/4-20 x 3/4” Pan HD Phil Cap
227270
2
GB16 Screw, 1/4-20 x 1/2 Hex Head Cap
152608
2
GB17 Washer, 1/4 Split Lock
152591
4
GB18 Washer, 1/4 SAE Flat
151915
4
GB19 Nut, 1/4-20 Hex
151893
2
GB20 Label, Control Panel, (Electric)
160109
1
H
Assembly, Axle
-
1
H1
Wheel, 8”Dia. X2
155986
2
H2
Collar, 3/4 set
153814
2
H3
Axle, 3/4 Dia.
157065
1
H4
Mount, Wheel Shaft,
157072
2
H5
Screw, 1/2-13 x 1 1/4 UNC Hex Head
153532
2
H6
Washer, 1/2 SAE Flat
150924
4
H7
Washer, 1/2 Split Lock
153524
2
J
Assembly, Handlebar (Top & Bottom)
-
1
J1
Handlebar, Top
157260
1
J2
Handgrip
150842
2
J3
Handlebar, Bottom
157070
1
J4
Screw, 3/8-16 X 1 Hex Head Cap
152507
1
J5
Screw, 3/8-16 X 1 1/4 Hex Head Cap
150774
4
J6
Screw, 3/8-16 X 3 Hex Head Cap
153113
4
J7
Washer, 3/8 SAE Flat
150923
8
J8
Washer, 3/8 Split Lock
150925
6
J9
Nut, 3/8-16 Hex
101188
2
K
Assembly, Throttle, Honda
-
1
K1
Screw, (Phil) Self Tap 10-24 x 5/8
153681
2
K2
Nut, 10-24 Clip
155407
2
K3
Assembly, Throttle Head
155406
1
K4
Cable, Throttle, Honda
156640
1
L
Assembly, Choke, Honda
-
1
MK-DDG SERIES PARTS LIST
