Mk-ddg series parts list – MK Diamond MK-DDG User Manual
Page 19
19
Item
Description
Part #
Qty
A
Assembly, Accessory Pack
-
-
A1
Grinding Wheels 10” (Reference only)
reference
0
A2
Pallet (not shown)
157700
1
A3
Carton, DDG-11 Grinder (not shown)
157701
1
A4
Carton, DDG-11 Top (not shown)
158369
1
A5
Carton, DDG-11 Inserts (not shown)
158370
2
A6
Tube, Owner’s Manual (not shown)
155419
1
A7
Manual, Owner’s (not shown)
157499
1
A8
Bolt, Hex HD, 3/8-24 x 1 Grinding Disk, Mounting
157803
8
A9
Washer, 3/8 Split Lock
150925
8
A10
Washer, 3/8 Flat SAE
150923
8
B
Assembly, Frame
157381
1
B1
Frame Weldment
157068
1
B2
Plate, Serial Number
157500
1
B3
#7 X 5/16 Drive Screw
157849
4
B4
Label, Water Shut Off/On
154404
1
C
Assembly, Apron
-
1
C1
Apron,
157064
1
C2
Plate, Vacuum
157255
1
C3
Cap, Vacuum Attachment
157503
1
C4
Screw, 5/16-18 x 1-1/4 Hex Head
153950
4
C5
Washer, 5/16 lock, split
151747
5
C6
Washer, 5/16 SAE Flat
151754
5
C7
Screw, 5/16-18 x 3/4 Hex Head
151369
1
C8
Label, Caution, Hands and Feet
155585
1
D
Assembly, Belt Guard
-
1
D1
Guard, Belt
157069
1
D2
Screw, ¼-20 X 1 Hex Head Cap
152676
2
D3
Washer, 1/4 SAE Flat
151915
4
D4
Nut, Hex W/ WSHR 1/4-20 (KEPS)
153941
2
D5
V-Belt (V AX-25)
152403
2
D6
Label, MK Logo Adhesive
157914
1
D7
Label, Caution, Belt Tension
155583
1
D8
Label, Caution, Guards in Place
155587
1
E
Assembly, Gear, Cover
-
1
E1
Cover, Gear
157066
1
E2
Screw, 1/4-20 x 3/4 Hex Head Cap
152370
9
E3
Washer, 1/4 Split Lock
152591
9
E4
Washer, 1/4 SAE Flat
151915
9
E5
Cap, Grease
157915
1
F
Assembly, Components, Gear Box
-
-
F1
Flange unit, 1” dia 4 Bolt (Bearing)
157305
4
F2
Washer, 7/16 Flat SAE
151050
16
F3
Washer, 7/16 Split Lock
151051
16
MK-DDG SERIES PARTS LIST
