20
Item Description Part # Qty
F4 Nut, 7/16-14, Hex 150922 16
F5 Flange unit, 3/4” dia 4 Bolt (Bearing) 157304 2
F6 Washer, 3/8 Flat SAE 150923 8
F7 Washer, 3/8 Split Lock 150925 8
F8 Nut, 3/8-16, Hex 101188 8
F9 Shaft, 1” dia Large Gear 157302 2
F10 Flexible Mount, Morflex (Morse 402 Insert) 157411 2
F11 Mount, Grinding Wheel 157407 2
F12 Screw, 3/8-16 x 2 1/2 Hex HD Cap 156030 4
F13 Screw, 3/8-16 x 2 1/2 Flt. Soc. HD. 157562 4
F14 Nut, 3/8-16, Hex Nylock 152505 8
F15 Bushing, 1 ¼ OD x 1 ID x ½ Spacer 157410 2
F16 Gear, 11 ½” dia Spur (Cast 10P 112T-14 ½ PA) 157306 2
F17 Key, Square, 1/4 x 1/4 x 1 ¼” 159852 2
F18 Shaft, ¾” dia Small Gear 157303 1
F19 Gear, 2 1/2” dia Spur (Steel 10P 25T-14 ½ PA) 157307 1
F20 Pin, 1/4 x 1 1/2” Rolled 157565 1
F21 Pulley, 2AK51H
F21A) Bushing, H 3/4 Q.D.
159849
159850
1
1
F22 Key, Square, 3/16 x 3/16 x 1 ¾ 157561 1
G Assembly, Engine, 11HP Honda - 1
G1 Engine, Honda GX340k2dx3 157067 1
G2 Clutch, 3 ½” OD with 1” I.D. 3 ½” 2 Groove Pulley, 157309 1
G3 Key, Square, 1/4 x 1/4 x 1 ½” 157560 1
G4 Bolt, 7/16-20 x 3” Hex Head 157678 1
G5 Washer, 1 /2” USS 157679 1
G6 Washer, 7/16 Split Lock 151051 1
G7 Spacer, 1 ¼” OD, 1” I.D. x 1 3/8” 157680 1
G8 Spacer, 1” OD, ½” I.D. x 2” 157681 1
G9 Screw, 5/16-18 x 1 1/2” Hex Head Cap 152467 2
G10 Bolt, 5/16-24 x 1” Hex Head Tap 157646 2
G11 Washer, 5/16 SAE Flat 101352 5
G12 Washer, 5/16 Split Lock 151747 5
G13 Nut, 5/16-18 Hex 101196 3
G14 Bolt, 5/16-18 x 2 ¾” Hex Head Tap 156974 1
G15 Mount, Engine 157071 1
G16 Screw, 3/8-16 x 1” Carriage Bolt 157644 4
G17 Washer, 3/8 SAE Flat 150923 4
G18 Washer, 3/8 Split Lock 150925 4
G19 Nut, 3/8-16 Hex 101188 4
G20 Hose, Oil Drain (20mm) 157577-04 1
G21 Label, Caution, Hot Surface, 1.5 x 3.0 155578 1
G22 Label, Warning, Refueling, 1.5 x 3.0 155580 1
G23 Label, Danger, California, 1.5 x 3.0 155581 1
G24 Label, Danger, Lethal Exhaust, 1.5 x 3.0 155582 1
G25 Label, Caution, Sparkplug 155579 1
G26 Label, Control Panel (Gas) 157075 1
MK-DDG SERIES PARTS LIST
