Follow the diagram below to prepare your MK-DDG for operation.
ASSEMBLY
Handlebar Adjustment
Adjust the Handlebar, as shown on the Figure to the right,
for ease of operation and comfort of the user.
Grinding Discs Assembly
You need to install the grinding discs before
operation of the MK-DDG
Operate on concrete
surface
Both grinding discs at
work
Check the surface
The Figure to the left shows
hardware and installation of discs.
Unit ready for operation.
One disc installed.
Grinding Wheel Mount
MK-DDG SERIES ASSEMBLY
