PRODUCT SPECIFICATIONS
The MK-DDG is a versatile unit. Operated and used according to this manual, the MK-DDG will

provide years of dependable service.

Features

Specifications

• Uses two 10 or 20 segment 10" diameter diamond grinding discs to level, smooth or

clean the top surface of concrete slabs.

• Provides a smoother finish compared to other methods such as scarifiers or scrabblers.

• Counter rotating discs provide balanced torque to prevent pulling left or right

• Can also be used to level small areas of uneven joints or high spots of 1/16" to 1/8".

• A 22-inch grinding width makes for quick removal.

• Wide ergonomically designed T-grip handle for easy handling and maneuvering.

• Dust shroud contains grinding debris.

• 2" vacuum port standard for dust-free operation.

• Two-position wheel carriage for grinding and easy transport.

• Works on concrete slabs, terrazzo, brick, stone and ceramic tile floors.

Specifications for the MK-DDG are listed in the table below.

Model

MK-DDG-11

MK-DDG-5 Electric

Engine

Honda

Baldor / Leeson

Power

GXV340

5 HP

Disc RPM

550

Disc Capacity

10" (254mm)

Weight

239 lbs. (108kg)

295 lbs. (134kg)

LxWxH (inches)

50" x 25" x 40"

LxWxH (mm)

1,270 x 635 x 1,016 1,270 x 635 x 1,016

Part #

157012

158780
