MK-S ParTS LiST
iTEM
DEScriPTion
QTY.
ParT#
1
NUT, HEx, 5/16 - 18
2
101196
2
BLADE, MK-304D 4 x 080x 20MM - 5/8
1
150686
3
NUT, HEx, 1/4 - 20
2
151893
4
SHIM, 1/2 OD x 5/16 ID x .004” THK.
4
152519
5
TAG, SERIAL NUMBER, BLANK
1
157500-RW
6
SCREW, SOCKET HEAD SET 10 -24 x 1/4
2
157552
7
DRIVE SCREW, #7 x 5/16 ROUND HEAD
2
157849
8
NUT, HEx, NYLK, 5/16 - 18
6
158289
9
CASTING, BASE COMP
1
168169
10
ASSY, CUTTING HEAD
1
168174
11
ARM, POINTER
2
168175
12
WHEEL, POINTER
2
168176
13
BEARING, WHEEL
8
168177
14
WHEEL, RUBBER 72MM
4
168178
15
SCREW, BHCS, 5/16 - 18 x 2
4
168195
16
WIPER, RUBBER
1
168217
17
SCREW, BHCS, 5/16 - 18 x 1
2
168219
18
SPACER, WHEEL 8MM x 12 .7MM x 10MM
4
168235
19
OWNERS, MANUAL, MK-S
1
168238
20
KNOB, 5/16 - 18 x 1
2
168239
21
STUD, 5/16 - 18 x 5
1
168240
22
STUD, 1/4 - 20 x 2-1/2
2
168241
23
SCREW, SOC HD SET, 5/16 18 x 3/8
1
168242
24
WRENCH, 1/8 HEx KEY
1
168263
25
LABEL, CARTON, MK-S
1
168553
26
NUT, HEx, NYLK, M6 - 1.0
1
168048
27
WASHER, FENDER, 1/4 x 1
1
168049
28
SCREW, CAP, SOC HD, M6 x 1 x 150MM
1
169050
29
SPACER, 1/4 x 11/16 x 3/4
1
168051
30
SPRING, TORSION, 35 IN-LB
1
168052
31
PIN, STOP, THREADED
1
168085
