F6
Washer, 5/16 SAE Flat
2
151754
G
Assembly, Linear Bearing
n/a
n/a
G1
Casting, Linear Bearing
1
A) Bearing, Multilube
2
135855
152227
G2
Screw, 5/16-18 X 1 Hex Head Cap
2
151743
G3
Washer, 5/16 Split Lock
2
151747
G4
Washer, 5/16 SAE Flat
2
151754
G5
Shim, .004 X 5/16 Id X 1/2 od
~4
152519
H
Assembly, Motor, 120V
n/a
n/a
H1
Motor, 120V/15A
1
155533
H2
Screw, 10-32 X 3/4 Flat Head Phillips Cap
2
153902
H3
Screw, 14mm X 30mm Flat Head Socket Cap
2
156174
H4
Flange, 2-3/8 Blade
2
135830
H5
nut, Blade Shaft, 5/8-16 UnF Hex
1
135848
H6
Label, Warning, Read owner’s Manual
1
155806
H7
Label, Caution, GFCI, 1 X 2 1/8
1
155678
H8
Label, Caution, 1 Amp Max., 1 X 2 1/8
1
154822
HA
Assembly, Motor, 240V
n/a
n/a
HA1 Motor, 240V/7.5A
1
156180
HA2 Screw, 1/4-20 X 3/4 Flat Head Phillips Cap
2
154657
HA3 Screw, 14mm X 30mm Flat Head Socket Cap
2
156174
HA4 Flange, 2-3/8 Blade
2
135830
HA5 nut, Blade Shaft, 5/8-16 UnF Hex
1
135848
HA6 Label, Warning, Read owner’s Manual
1
155806
HA7 Label, Caution, GFCI, 1 X 2 1/8
1
155678
HA8 Plug, nEMA6-15P 220V/15A
1
155391
HB
Assembly, Motor, 240V, Australia
n/a
n/a
HB1 Motor, 240V/7.5A
1
156180
HB2 Screw, 1/4-20 X 3/4 Flat Head Phillips Cap
2
154657
HB3 Screw, 14mm X 30mm Flat Head Socket Cap
2
156174
HB4 Flange, 2-3/8 Blade
2
135830
HB5 nut, Blade Shaft, 5/8-16 UnF Hex
1
135848
HB6 Label, Warning, Read owner’s Manual
1
155806
HB7 Label, Caution, GFCI, 1 X 2 1/8
1
155678
HB8 Plug, 240V/10A Australia
1
156267
J
Assembly, Motor Mount
n/a
n/a
J1
Mount, Motor
1
155694
J2
Screw, 1/2 X 3/4 Socket Head Shoulder,
w/ 3/8-16 X 5/8 thread
1
156177
J3
Screw, 1/2 X 1-1/4 Socket Head Shoulder,
w/ 3/8-16 X 5/8 thread
1
156176
J4
Spring, Miter
1
155696
J5
deflector, Air
1
155695
J6
Screw, 10-24 X 1/2 Pan Head Phillips Cap
2
151744
K
Assembly, Post
n/a
n/a
K1
Casting, Post
1
155670
K2
Plate, Pressure
1
155671
K3
Screw, 3/8-16 X 2 1/2 Hex Head Cap
2
227178
K4
Washer, 3/8 Split Lock
2
150925
K5
Shaft, 10.63” Pivot
1
153254
K6
Screw, 3/8-16 X 1/2 Socket Head Set
1
153710
K7
Stop, Cutting Head
1
156256
K8
Screw, 10-32 X 1 Pan Head Slotted Cap
1
156270
K9
nut, 10-32 Hex
1
156269
K10 Screw, 1/4-20 X 1 1/4 Hex Head Cap
1
152122
K11 Washer, 1/4 Split Lock
1
152591
