MK-1070 Parts List
Models
Part #
description
155882
MK-1070 Tile Saw 120V/17.6A
155885
MK-1070 Tile Saw 240V/7.5A
156182
MK-1070 Tile Saw 240V/7.5A, Australia
Item description
Qty
Part #
A
Assembly, Accessory Pack
n/a
n/a
A1
Carton, Accessory Pack
1
156178
A2
Foam, Accessory Pack Carton
1
156179
A3
owner’s Manual, 1070
1
156172
A4
Card, MK Warranty Registration
1
155037
A5
Blade, MK-415 Continuous Rim Wet Tile,
10 dia. X 5/8 arbor X .080 X 10mm segment
1
155619
A6
Wrench, Blade nut, 15/16 Closed End
1
134684
A7
Casting, Rip Guide
1
134551
A8
Casting, Large Rip Guide
1
154014
A9
Casting, dual 45° Flat Angle Guide
1
134577
A10 Protractor
1
134569
A12 Stick, dressing, 60 Grit, 8 X 2 X 1
1
152792
B
Assembly, Blade Guard
n/a
n/a
B1
Casting, Blade Guard
1
155699
B2
Tube, 2.5” Water
2
155512
B3
Screw, 5/16-18 X 1/4 Socket Head Set
2
152607
B4
Fitting, Brass, 1/8 MnPT X 1/4 BARB
1
155809
B5
Stud, 5/16-18 X 1 1/2, Full Thread
1
153680
B6
Knob, davies
1
151681
B7
Wingnut, 5/16-18 nylock
1
151746
B8
Washer, 5/16 SAE Flat
2
151754
B9
Label, Caution, Hearing Protection
1
156687
C
Assembly, Carton
n/a
n/a
C1
Carton
1
156268
C2
Pallet
1
153901
d
Assembly, Cutting Head
n/a
n/a
d1
Head, Cutting
1
155692
d2
Knob, 3/8-16 X 1 Adjustment
1
137786
d3
Washer, 3/8 SAE Flat
1
150923
d4
Knob, 3/8-16 X 1 Three Prong
1
156175
d5
Tag, Serial number
1
156173
d6
Tack, Metal. 1/4 Head
2
155659
d7
Screw, 10-32 X 1 Hex Head Cap
2
156270
d8
nut, 10-32 Hex
2
156269
E
Assembly, Frame
n/a
n/a
E1
Pan, Water
1
153262
E2
Plug, Rubber drain
1
153439
E3
Frame, 21 X 41
1
153209
E4
Plate, Adjustment
2
151758
E5
Pin, 3/16 X 3/8 Roll
2
151783
F
Assembly, Guide Bar
n/a
n/a
F1
Bar, 3/4 X 37 Guide
1
153492
F2
Cover, Guide Bar
1
153219
F3
Spacer, Guide Bar Cover
2
152393
F4
Screw, 5/16-18 X 1 Hex Head Cap
2
151743
F5
Washer, 5/16 Split Lock
2
151747
Parts Listing- MK-1070 Tile Saw
