21
(K)
Lubricate the Roller Wheel
Assembly
(J)
Lubricate the Guide Bar
To extend the life of the MK-370 Saw, the following procedure should be performed
after each use. Lubricate all points listed below with light oils such as, 3 in 1, WD-40,
CAUTION
LOCKOUT
The MK-370 Saw is equipped with a lockout device that can be used during maintenance and
troubleshooting to render the saw in operable. The lockout can also be used to prevent unauthorized
(A)
Locate the Lockout Pin in the
center of the ON/OFF Switch
toggle (the Lockout Pin has
"Remove To Lock" highlighted)
(B)
Lockout the Saw by removing
thett Pin
MAINTENANCE
Monthly Maintenance
The following maintenance should be performed monthly.
(B)
Clean the Motor Shaft
(A)
Remove and clean the Inner
and Outer Flanges and the
Blade Retaining Nut
(C)
Lubricate the Motor Shaft
MK-370 SAW MAINTENANCE
