Page 14
PVL-14
V-LINE 32
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
U
niversal
r
idge
d
eTail
g
ravel
s
ToP
d
eTail
1:12 Slope
Minimum
v-line 32
Tape Sealant
V-Line 32 Panel
#12-14 x 1
1
/
2
" SD (see below)
#
1
/
4
-14 x
7
/
8
" Stitch Screw (1'-0" o.c.)
Universal Ridge Cover
V-Line 32 Closure (Outside)
V-Line 32 Panel
Cleat
Fastener (by others)
#12-14 x 1
1
/
2
" SD (see below)
Gravel Stop
Tape Sealant
1
/
8
x
3
/
16
" Pop-Rivet (1'-0" o.c.)
V-Line 32 Closure (Outside)
Tape Sealant
#
1
/
4
-14 x
7
/
8
" Stitch Screw (1'-0" o.c.)
#12-14 x 1
1
/
2
" Self Driller
Tape Sealant (roof only)
V-Line 32 Fastening Pattern
#
1
/
4
-14 x
7
/
8
" Stitch Screw (1'-0" o.c.)
#12-14 x 1
1
/
2
" Self Driller
Tape Sealant (roof only)
V-Line 32 Fastening Pattern
