Metal Sales T10-C User Manual
Page 10
PV-10
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
V
erti
-L
ine
S
erieS
C
oPing
d
eTail
(v
erTiCal
)
C
oPing
d
eTail
(h
orizonTal
)
#12-14 x 1
1
/
4
" SD (1'-0" o.c.)
Cleat
Verti-Line Panel
Tape Sealant (optional)
v
erTi
-l
ine
s
eries
#12-14 x 1
1
/
4
" SD
Outside Closure
1
/
8
" x
3
/
16
" Pop-Rivet (1'-0" o.c.)
#12-14 x 1
1
/
4
" SD (1'-0" o.c.)
Verti-Line Panel
#12-14 x 1
1
/
4
" SD
1
/
8
" x
3
/
16
" Pop-Rivet (1'-0" o.c.)
Coping
Cleat
Coping
