MAGNA-LOC
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
ssr s
CUlPTUred
r
ake
(o
ff
M
odUle
) d
eTail
1
/
2
:12 SLOPE
MINIMUM
Magna-Loc Panel (field cut and bend)
Rake Angle (by others)
#
1
/
4
-14 x
7
/
8
" Stitch XL (1'-0" o.c.)
SSR Sculptured Rake (off module)
Double Bead Tape Sealant
SSR Rake Cleat
Floating Rake Zee
#12-14 x 1
1
/
4
" SD XL (1'-0" o.c.)
1
/
4
"-14 x 1
1
/
4
" Shoulder SD (1'-0" o.c.)
SSR Rake Slide
1
/
4
"-14 x
7
/
8
" Stitch XL (1'-0" o.c.)
Double Bead Tape Sealant
2"
CAUTION
Note: If panel does termi-
nate on module then Rake
Cleat is not needed.
