Magna-loc, 9" d – Metal Sales Magna-Loc 180 User Manual
Page 21
PML-21
MAGNA-LOC
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
9" d
roP
v
alley
d
eTail
3:12 SLOPE
MINIMUM
Magna-Loc Panel (field cut)
(2) rows of Tube Sealant (between panel ribs)
Double Bead Tape Sealant
SSR 9" Drop Valley
Eave Plate
#12-14 x 1" SD N/W (1'-0" o.c.)
#12-14 x 1
1
/
4
" SD XL (see below)
Valley Plate
#12-14 x 1
1
/
4
" SD XL
1
3
2
5
4
Magna-Loc Fastening Pattern
