PIC-13
IC72-PANEL
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
#12-14 x 1 1 /
4
" SD
1 /
4
"-14 x 7 /
8
" Stitch Screw (1'-0" o.c.)
Tape Sealant
IC72-Panel Fastening Pattern
#12-14 x 1 1 /
4
" SD
1 /
4
"-14 x 7 /
8
" Stitch Screw (1'-0" o.c.)
Tape Sealant
IC72-Panel Fastening Pattern
u
niversal
r
idge
d
eTail
g
ravel
s
ToP
d
eTail
iC72-Panel
1:12 Slope
Minimum
Universal Ridge Cover
IC72 Roof Panel
Tape Sealant
#12-14 x 1 1 /
4
" SD (see below)
IC72-Panel Closure
1 /
4
"-14 x 7 /
8
" Stitch Screw
Tape Sealant
Gravel Stop
Tape Sealant
#12-14 x 1 1 /
4
" SD (see below)
IC72-Panel Closure
IC72 Wall Panel
1 /
4
"-14 x 7 /
8
" Stitch Screw (1'-0" o.c.)
Fastener (by others)
