PIC-11

IC72-PANEL

© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11

800.406.7387 (Corporate Office) • www.metalsales.us.com

r

akewall

d

eTail

e

ndwall

d

eTail

iC72-Panel

1:12 Slope

Minimum

Tape Sealant

IC72 Wall Panel

Rakewall

Tape Sealant

1

/

4

"-14 x

7

/

8

" Stitch Screw (1'-0" o.c.)

#12-14 x 1

1

/

4

" SD (see below)

IC72-Panel Closure

IC72 Roof Panel

IC72 Wall Panel

Tape Sealant

#12-14 x 1

1

/

4

" SD (see below)

IC72-Panel Closure

1

/

4

"-14 x

7

/

8

" Stitch Screw (1'-0" o.c.)

Pitch Break

Tape Sealant
IC72-Panel Closure
Tape Sealant
IC72 Roof Panel

#12-14 x 1

1

/

4

" SD

1

/

4

"-14 x

7

/

8

" Stitch Screw (1'-0" o.c.)

Tape Sealant

IC72-Panel Fastening Pattern

#12-14 x 1

1

/

4

" SD

1

/

4

"-14 x

7

/

8

" Stitch Screw (1'-0" o.c.)

Tape Sealant

IC72-Panel Fastening Pattern
