cabinetry/Joinery Bits
Carbide Tipped Rabbeting Bits
Micrograin control cut bits for making rabbeting cuts without the use
of a router guide.
• To increase the width of rabbet by 1/16" for 85218M and 85590M,
purchase 3/8" diameter bearing 3 600 900 501 and dust shield 3 600 120 507
A
D
E
C
B
Item #
Rabbet
Width
A.
Overall
Diameter
B.
Cutting
Edge Lgth.
C.
Shank
Diameter
D.
Overall
Length
E.
Bearing
Diameter
85218M
3/8"
1-1/4"
1/2"
1/4"
2"
1/2"
85590M
3/8"
1-1/4"
1/2"
1/2"
2-3/8"
1/2"
85614M
1/2"
1-3/8"
1/2"
1/4"
2"
1/2"
85615M
1/2"
1-3/8"
1/2"
1/2"
2-3/8"
1/2"
Carbide Tipped Keyhole Bits
For plunge and slots cuts. Route mounting slots in picture frames and plaques.
• 85608M is a carbide tipped bit
• 85078 is a high speed steel bit
A
A
D
1
1
2
2
C
B
B
Carbide Tipped Dovetail Bits
Micrograin bits for making dovetail joints.
A
D
C
B
Item #
A1.
Large
Diameter
A2.
Small
Diameter
B.
Cutting
Edge
C.
Shank
Diameter
D.
Overall
Length
85078
3/8"
3/16"
3/16"
1/4"
1-7/8"
85608M
3/8"
3/16"
3/8"
1/4"
1-1/2"
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
Degree
84706M
3/8"
3/8"
1/2"
2-1/2"
9
84700M
3/8"
3/8"
1/2"
2"
9
84702M
3/8"
3/8"
3/8"
2"
9
84703M
1/2"
1/2"
1/4"
2"
14
84709M
1/2"
17/32"
1/2"
2-1/2"
14
85240M
17/32"
1/2"
1/4"
1-7/8"
15
84712M
5/8"
7/8"
1/2"
2-5/8"
7
84710M
3/4"
3/4"
1/2"
3"
14
84715M
3/4"
7/8"
1/2"
2-5/8"
7
84705M
1"
1"
1/2"
2-3/4"
14
Carbide Tipped Drawer Lock Joint Bit
Micrograin control cut bit for constructing durable drawer joints.
• Recommended for use with a router table
A
D
C
B
Carbide Tipped Lock Miter Bit
Micrograin control cut bit for making right angle joints and glue joints.
• Recommended for use with a router table
A
D
C
B
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
84512M
1"
1/2"
1/2"
1-5/16"
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
84508M
2-11/16"
1-3/16"
1/2"
2-5/8"
Carbide Tipped Reversible Glue Joint Bit
Micrograin control cut bit used for making glue-ups and strong joints
in door panels, tabletops and more.
• Recommended for use with a router table
A
D
C
B
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
84505M
1-7/8"
1-3/32"
1/2"
2-5/8"
