Page 26: Carbide tipped v-groove & scoring bits, Solid carbide veining bits, Carbide tipped beading bit, Carbide tipped classical bits, Carbide tipped ogee bits
130
Boschtools.com
Toll Free: 877-BOSCH-99
Router
bits
Surface Forming Bits
A
D
E
C
B
Carbide Tipped V-groove & Scoring Bits
Micrograin bits ideal for door-front grooving, lettering and sign work. Features
shear angle cutter geometry for smooth, efficient cutting.
Solid Carbide Veining Bits
Provincial design veining bits are intended for recessed design veining
in fine cabinet surfaces and used extensively for door front grooving.
A
D
C
B
E
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
E.
Bevel
84300M
1/2"
5/8"
1/4"
1-3/4"
1/4" (45°)
84303M
5/8"
1/2"
1/2"
2"
7/16" (45°)
84306M
3/4"
5/8"
1/2"
2-1/8"
19/32" (45°)
85219M
9/16"
3/4"
1/4"
1-3/4"
3/8" (45°)
84309M
1"
5/8"
1/2"
2-1/4"
13/16" (45°)
85220M
1-1/4"
15/16"
1/4"
2-13/64"
7/8" (45°)
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
E.
Radius
85281M
1/8"
5/32"
1/4"
1-1/2"
1/16"
85282M
3/16"
25/64"
1/4"
1-1/2"
3/32"
85283M
1/4"
25/64"
1/4"
1-1/2"
1/8"
Top Bearing Mounted – Carbide Tipped Classical Bits
Top bearing mounted bits are ideal for templet cutting, grooving,
lettering and plunge cutting from above and below the workpiece.
Rides against template for pattern routing.
• Replacement collar 3 600 231 500
• Replacement set screw 3 603 401 506
A
D
E
E
C
B
Carbide Tipped Beading Bit
Micrograin bit used extensively for provincial design in doors.
A
D
E
F
C
B
Carbide Tipped Classical Bits
Micrograin bits are used for beautiful, decorative grooving, adding a quality
accent to any project. Also recommended for edge forming with a router guide.
A
D
E
C
B
Item #
A.
Overall
Diameter
B.
Cutting
Edge Lgth.
C.
Shank
Diameter
D.
Overall
Length
E.
Small
Diameter
F.
Radius
85478M
3/8"
5/16"
1/4"
2"
3/16"
3/32"
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
E.
Radius
85467M
1/2"
7/16"
1/4"
2"
3/32"
85468M
3/4"
1/2"
1/4"
2-1/16"
9/64"
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
E.
Radius
85688M
1/2"
7/16"
1/4"
2"
3/32"
85689M
3/4"
1/2"
1/4"
2-1/16"
9/64"
A
D
E
F
C
B
Carbide Tipped Ogee Bits
Micrograin bits add a graceful, symmetrically-balanced ogee cut for eye-
pleasing appeal. Recommended for both grooving and edge-forming cuts.
Item #
A.
Overall
Diameter
B.
Cutting
Edge Lgth.
C.
Shank
Diameter
D.
Overall
Length
E.
Small
Diameter
F.
Radius
85461M
3/8"
5/16"
1/4"
2"
.123
1/16"
85462M
1/2"
3/8"
1/4"
2"
.157
5/64"
85463M
3/4"
1/2"
1/4"
2-1/8"
.249
9/64"
85464M
3/4"
1/2"
1/2"
2-3/4"
.256
9/64"
