Page 20: Carbide tipped ogee & bead bit with fillet, Carbide tipped reverse curve ogee & bead bit, Carbide tipped plunge roundover bits, Carbide tipped multi-form bit, Carbide tipped multi-profile bit, Carbide tipped table edge bit, Carbide tipped cove & bead large bit
124
Boschtools.com
Toll Free: 877-BOSCH-99
Router
bits
Edge Forming Bits
Carbide Tipped Ogee & Bead Bit with Fillet
Classical architectural molding micrograin bit for making furniture and cabinet
molding, door and window casing and other millwork.
• Recommended for use with a router table
A
D
E
F
G
C
B
Item #
A.
Overall
Dia.
B.
Cutting
Edge Lgth.
C.
Shank
Dia.
D.
Overall
Length
E.
Bearing
Dia.
F.
Large
Radius
G.
Small
Radius
84621M
1"
1-11/16"
1/2"
3-1/4"
1/2"
3/8"
1/8"
Carbide Tipped Reverse Curve Ogee & Bead Bit
Classical architectural molding micrograin bit for making furniture and cabinet
molding, door and window casing and other millwork.
• Recommended for use with a router table
A
E
F
G
D
C
B
Item #
A.
Overall
Dia.
B.
Cutting
Edge Lgth.
C.
Shank
Dia.
D.
Overall
Length
E.
Bearing
Dia.
F.
Large
Radius
G.
Small
Radius
84620M
7/8"
1-3/8"
1/2"
3-3/8"
1/2"
5/16"
5/32"
Carbide Tipped Plunge Roundover Bits
Micrograin control cut bits for special decorative grooving and edging.
A
D
E
F
C
B
Item #
A.
Overall
Diameter
B.
Cutting
Edge Lgth.
C.
Shank
Diameter
D.
Overall
Length
E.
Small
Diameter
F.
Radius
85470M
1"
5/8"
1/2"
2-1/8"
1/4"
3/8"
85471M
3/4"
1/2"
1/2"
2"
1/4"
1/4"
85472M
1-3/8"
1"
1/2"
2-1/2"
3/8"
1/2"
Carbide Tipped Multi-form Bit
Micrograin bit achieves many profiles and architectural designs. With a simple
adjustment to the cutter height and fence position, 50 molding patterns are available.
•
Recommended for use with a router table
A
D
E
C
B
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
E.
Bearing
Diameter
85700M
2-1/4"
1-7/8"
1/2"
2-3/4"
1/2"
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
E.
Bearing
Diameter
84515M
2-3/4"
5/8"
1/2"
2-1/2"
1/2"
Carbide Tipped Multi-profile Bit
Micrograin control cut bit for creating an unlimited variety of profiles by varying
cutter height, fence position and number of passes.
A
D
C
B
Carbide Tipped Table Edge Bit
Creates a wide profile for attractive edging and curve for tables or handrails.
A
D
C
B
E
Item #
A.
Overall
Diameter
B.
Cutting
Edge Length
C.
Shank
Diameter
D.
Overall
Length
84532M
7/8"
1-1/32"
1/2"
2-3/4"
Carbide Tipped Cove & Bead Large Bit
Classical architectural molding micrograin bit for making furniture and cabinet
molding, door and window casing and other millwork.
•
Recommended for use with a router table
A
F
E
G
D
C
B
Item #
A.
Overall
Dia.
B.
Cutting
Edge Lgth.
C.
Shank
Dia.
D.
Overall
Length
E.
Bearing
Dia.
F.
Large
Radius
G.
Small
Radius
84612M
7/8"
1-1/2"
1/2"
3-3/8"
1/2"
5/16"
5/32"
