Key for overview
Position Description
0 Controller
1 Fixing bracket for standard mounting
2 EMC shield sheet with fixing screws for shielded control cables
3 Cover with fixing screws
4 Shield clamp and strain relief for the motor cable
5 Strain relief for the PE motor cable and the feed cable for the motor temperature monitoring with PTC thermi-
stor or thermal contact (NC contact)
Connections and interfaces
Position Description
L1, L2, L3, PE Mains connection
+UG, −UG DC supply
U, V, W, PE Motor connection
T1, T2 Connection of PTC thermistor or thermal contact (NC contact) of the motor
X1 AIF interface (automation interface)
Slot for communication module (e. g. XT EMZ9371BC keypad)
X3 Jumper for setting analog input signal at X6/1, X6/2
X4 System bus (CAN) connection
X5 Connection of digital inputs and outputs
X6 Connection of analog inputs and outputs
X8 Connection of incremental encoder with TTL level or SinCos encoder and KTY temperature sensor of the motor
X9 Connection of digital frequency input signal
X10 Connection of digital frequency output signal
X11 Connection of K
SR
relay output for "safe standstill" (for variants V004 and V024 only)
Status displays
Position LED red LED green Operating status

Off On Controller is enabled
On On Mains is switched on and automatic start is inhibited
Off Blinking slowly Controller is inhibited
Off On Motor data identification is active
Blinking quickly Off Undervoltage or overvoltage
Blinking slowly Off Active fault
