Technical Data
3-4 UOMu_^MVMO
3.3 Fuses and cable cross-sections
3.3.1 Single drives with 150 % overload
qЬЙ н~ДдЙ о~дмЙл ~кЙ о~дбЗ Сзк нЬЙ зйЙк~нбзе зС UOuu ЕзенкзддЙкл ~л
лбеЦдЙ ЗкбоЙл пбнЬ ~ г~нЕЬбеЦ гзнзк ~еЗ NRM B зоЙкдз~ЗK
Type Mains input L1, N, PE / motor connection U, V, W, PE Type
Operation without mains filter/mains choke Operation with mains filter/mains choke
Fuse
F1, F2, F3
E.l.c.b. Cable
cross-section 1)
Fuse
F1, F2, F3
E.l.c.b. Cable
cross-section 1)
VDE UL VDE mm 2 AWG VDE UL VDE mm 2 AWG
8201 M 10A - C 10A 1.5 15 M 10A - C 10A 1.5 15
8202 M 15A - C 16A 2.5 13 M 15A - C 16A 2.5
[1.5] 13
[15]
8203 M 20A - C 20A 4 11 M 15A - C 16A 2.5
[1.5] 13
[15]
8204 - - - - - M 20A - C 20A 4
[2.5] 11
[13]
Values in square brackets are valid for motor connection
1) Observe national and regional regulations (e. g. VDE/EVU)!
3.4 Dimensions
qЬЙ ЕзенкзддЙк ЗбгЙелбзел ЗЙйЙеЗ зе нЬЙ гЙЕЬ~ебЕ~д белн~дд~нбзе
EëÉÉ ЕЬ~йнЙк QKNFK
