8201BB operating module
for 8200 inverter series
MA8201BB 2.0
l Lenze Drive Systems GmbH, Postfach 10 13 52, D-31763 Hameln
( (+49) 5154 82-0, Fax Service: (+49) 5154 82-1112
These Instructions
Ÿ describe the handling and the installation of the 8201BB operating module.
Ÿ are only valid together with the Operating Instructions of the corresponding
frequency inverter.
Description
The 8201BB operating module is used for parameterization of the 8200 frequency
inverters via keypad. It includes a five-digit LCD display and six function keys.
Functions
Ÿ Parameterization of the frequency inverters
Ÿ Display of parameters and error messages
Ÿ Setpoint input via keypad
Ÿ Controller inhibit and enable via keypad
Ÿ Parameter transfer to other frequency inverters of the same series.
- The parameter transfer to frequency inverters of different series is not possible
because of the different code sets!
Application range
Applicable with frequency inverters with the following nameplate data:
Ÿ Frequency inverter 8200
- 820XE.0x.0x
- 821XE.0x.0x
- 822XE.0x.0x
- 824XE.0x.0x
Assembly
Ÿ The operating module can be connected to or disconnected from the X1 interface
during operation.
Ÿ The operating module is ready for operation when a text is displayed after the
initialization.
EDK8201BB
00459192
10/02
