Preface and general information
Scope of supply
1
l
54 EDBPM−H502 DE/EN/FR 5.1
For the use of the transmission cable, follow our recommendations:
Specification of the transmission cable
Total length £ 300 m £ 1000 m
Cable type LIYCY 2 x 2 x 0.5 mm2
(paired with shielding) CYPIMF 2 x 2 x 0.5 mm 2
(paired with shielding)
Cable resistance £ 80 W/km £ 80 W/km
Capacitance per unit
length £ 130 nF/km £ 60 nF/km
The following pictographs and signal words are used in this documentation to
indicate dangers and important information:
Safety instructions
Structure of safety instructions:
}
Danger!
(characterises the type and severity of danger)
Note
(describes the danger and gives information about how to prevent
dangerous situations)
Pictograph and signal word Meaning
{
Danger!
Danger of personal injury through dangerous electrical
voltage.
Reference to an imminent danger that may result in
death or serious personal injury if the corresponding
measures are not taken.
}
Danger!
Danger of personal injury through a general source of
danger.
Reference to an imminent danger that may result in
death or serious personal injury if the corresponding
measures are not taken.
(
Stop!
Danger of property damage.
Reference to a possible danger that may result in
property damage if the corresponding measures are not
taken.
