RG-MHMET 8
N2 Points
Point Description
1-08: PID Setpoint Command
This point is for monitoring the commanded PID Setpoint and is displayed in the drive’s
internal PID units with a range of 0-32736. A value of 0 represents the lower of Drive
Parameter #75 (Feedback @ Min) and Drive Parameter #76 (Feedback @ Max). A value
of 32736 represents the higher of Drive Parameter #75 (Feedback @ Min) and Drive
Parameter #76 (Feedback @ Max).
1-09: PID Feedback
This point is for monitoring the current PID Feedback value at the input specified by Drive
Parameter #74 (PID Feedback). It is displayed in the drive’s internal PID units with a range
of 0-32736. A value of 0 represents the lower of Drive Parameter #75 (Feedback @ Min)
and Drive Parameter #76 (Feedback @ Max). A value of 32736 represents the higher of
Drive Parameter #75 (Feedback @ Min) and Drive Parameter #76 (Feedback @ Max).
1-10: Present Fault
This point indicates the type of fault on which the drive is currently tripped. This point returns
a value between 0 and 24 which corresponds to one of the following fault conditions:
Value Fault
0 NO FAULT
1 OUTPUT FAULT
2 E-STOP
3 HIGH DC BUS VOLTS
4 HIGH DRIVE TEMPERATURE
5 THERMAL OVERLOAD
6 OUTPUT FAULT
7 LOW DC BUS VOLTS
8 START ERROR
9 DC BRAKE ERROR
10 FOLLOWER LOSS
11 DB ERROR
12 POWER SAG
13 CONTROL FAULT
14 LANGUAGE
15 EXTERNAL FAULT
16 INTERNAL16
17 POWER TRANSIENT
18 S/W ERROR #1
19 S/W ERROR #2
20 S/W ERROR #3
21 S/W ERROR #4
22 S/W ERROR #5
23 GENERAL S/W ERROR
24 SERIAL COMMUNICATION LOSS
