N2 Points
4.2 Analog Input (AI) Point Descriptions
Point Description
1-01: Actual Frequency
This point represents the actual speed of the drive in Hz.
1-02: Command Frequency
This point represents the commanded drive speed in Hz.
1-03: Load Percent
This point represents the drive’s load current as a % of rated current. This value can also
be seen on the local display.
1-04: Total Runtime
This point represents the number of hours that the drive has been running since its first
power-up.
1-05: DC Bus Voltage
This point represents the drive's DC Bus Voltage as a percentage of the nominal DC bus
voltage.
1-06: Operational Status
This point is for monitoring the actual operating condition of the drive. The value returned
is a number between 0 and 10 which corresponds to one of the following operating states:
Value Operational State
0 FAULT LOCKOUT
1 FAULT
2 START PENDING
3 STOP
4 DC BRAKE
5 RUN AT 0Hz
6 RUN
7 ACCEL
8 DECEL
9 CURRENT LIMIT
10 DECEL OVERRIDE
1-07: H/O/A Mode
This point is for monitoring the drive H/O/A status. If the drive H/O/A is OFF, this point
will return 0 and serial speed/setpoint and serial start commands will not be accepted.
If the drive H/O/A is HAND, this point will return 1 and serial speed/setpoint and serial
start commands will not be accepted. If the drive H/O/A is AUTO, this point will return 2
and, depending on the setting of Drive Parameter #30 (Control), serial speed/setpoint and
serial start commands will be accepted. For more information, refer to Section 3.1 Serial
Communication Setup.
