Lenze MC Series Drives - Manual (Page 26)

RG-MCMOD 22
Drive Control & Communication
AC Tech
Register
Number
(hexadecimal
representation)
Parameter
1
Parameter Name Range of Adjustment
Modbus value (decimal value) Factory Default
76 (4C) 25 2,3 START 00 - Normal
01 - Power-Up
02 - Auto Re-
03 - Re-Brake 00 - Normal
76 (4C) 25 4 START 00 - Normal
01 - Power-Up
02 - Auto 1
03 - Auto 2
04 - Auto 3 00 - Normal
77 (4D) 26 STOP 00 - Ramp
01 - Coast 01 - Coast
78 (4E) 27 2,3 ROTATION 00 - Forward
01 - Reverse
02 - FWD & REV
03 - FWD@LOC 00 - Forward
79 (4F) 28 2,3 AUTO/MAN 00 - Both
01 - Auto
02 - Manual 00 - Both
79 (4F) 28 4 AUTO/MAN 00 - A/M LOC
01 - Auto
02 - Manual
03 - A/M SPD 00 - A/M LOC
80 (50) 29 2,3 MANUAL 00 - Keypad
01 - 0-10 VDC 00 - Keypad
81 (51) 30 2,3 CONTROL 00 - Local
01 - Remote
02 - Both 00 - Local
81 (51) 30 4 CONTROL 00 - Local
01 - Remote
02 - Serial
03 - Keypad
04 - TB Strip
05 - Keypad 00 - Local
82 (52) 31 2 HZ UNITS 00 - Hertz
01 - RPM
02 - % Hz
03 - /SEC
04 - /MIN
05 - /HR
06 - GPH
07 - None 00 - Hertz
1 = Drive's programming parameter number; 2 = MC1000 without PID (SW ver 213-083, rev 13 or older); 3 = MC1000 with PID; 4 = MC3000
