Technical data
L
47 EDBEPM-H510 DE/EN/FR 4.0
2.2 Electrical data
Field Values
Display Type LCD monochrom STN, 5.5 “ Display
Display format graphical
Touch screen Matrix 20 8 (12 16 pixel)
Resolution 240 x 128 pixel
Visible size 123.0 x 68.0 mm
Lines Characters
100 %
200 %
400 % 16 x 40
8 x 20
4 x 10
Character size
100 %
200 %
400 % 3 x 4 mm, text: 6 x 8 pixel
6 x 8 mm, text: 12 x 16 pixel
12 x 16 mm, text: 24 x 32 pixel
Fonts programmable
Contrast setting via touch screen
Background light
Service life at 25 °C
CCFL tube
15000 h
Electrical connection DC voltage supply +18 ... 32 VDC Electrical connection
Power consumption 15 W at 24 VDC
Fusing Miniature fuse ∅ 5 20 mm, 800 mA / F
Network:
System bus (CAN)
Protocol Lenze System bus (CAN) System bus (CAN)
Communication medium DIN ISO 11898
Network topology Line (terminated at both ends with 120 Ω )
System bus participants Master or slave
Max. number of participants 63
Baud rate [kBit/s] 20 50 125 250 500 1000
Max. bus length [m] 2500 1000 500 250 80 25
Memory User program 512 kB Memory
Data memory
(energy-dependent, can only be
used with an internal buffer
battery)
128 kB
Interfaces Serial Interfaces
MSP (DB25 socket) RS232
Battery Saving of internal data and
real-time clock with data
Lithium battery 3 V, ∅ 19 mm
