Preface and general information
L
44
EDBEPM-H510 DE/EN/FR 4.0
1
Preface and general information
The
EPM-H510 keypad can be used to access codes of lenze controllers, 9300 Servo PLC and Drive
PLC and control these units. Communication takes place via system bus (CAN).
The
HMI Designer is a powerful development tool for creating projects containing the configuration
of the keypad.
1.1
About these Operating Instructions
!
These Operating Instructions are designed to describe safe and trouble-free working on and
with the EPM-H510 keypad.
!
All persons working on and with the EPM-H510 keypad must keep these Operating Instructions
to hand and observe all relevant information and notes.
!
These Operating Instructions must always be kept as a complete document and in a readable
state.
1.2
Terminology used
Term
In the following text used for
Drive controller
Lenze 8200 and 8200 vector frequency inverters, 9300 servo inverters
HMI
Human Machine Interface
1.3
Scope of supply
Scope of supply
Important
•
1 EPM-H510 keypad
•
1 Operating Instructions
•
4 Fixing clamps
•
4 M4 screws 35 mm
•
1 Seal
•
1 Terminal strip, 4-pole for DC voltage supply
•
1 Terminal strip, 5-pole for system bus connection
(CAN)
After receipt of the delivery, check immediately
whether the scope of supply matches the
accompanying papers. Lenze does not accept any
liability for deficiencies claimed subsequently.
Report
•
visible transport damage immediately to the
forwarder.
•
visible deficiencies/incompleteness immediately to
your Lenze representative.
