Key for overview
Position
Description
0
Controller
1
Fixing bracket for standard mounting
2
EMC shield sheet with fixing screws for shielded control cables
3
Cover with fixing screws
4
EMC shield sheet for the motor cable and the feed cable for the motor temperature monitoring with PTC ther-
mistor or thermal contact (NC contact)
Connections and interfaces
Position
Description
L1, L2, L3, PE Mains connection
+UG, −UG
DC supply
U, V, W, PE
Motor connection
T1, T2
Connection of PTC thermistor or thermal contact (NC contact) of the motor
X1
AIF interface (automation interface)
Slot for communication module (e. g. XT EMZ9371BC keypad)
X3
Jumper for setting analog input signal at X6/1, X6/2
X4
System bus (CAN) connection
X5
Connection of digital inputs and outputs
X6
Connection of analog inputs and outputs
X7
Connection of resolver and KTY temperature sensor of the motor
X8
Connection of incremental encoder with TTL level or SinCos encoder and KTY temperature sensor of the motor
X9
Connection of digital frequency input signal
X10
Connection of digital frequency output signal
X11
Connection of K
SR
relay output for "safe standstill" (for variants V004 and V104 only)
Status displays
Position
LED red
LED green
Operating status
Off
On
Controller enabled
On
On
Mains is switched on and automatic start is inhibited
Off
Blinking slowly
Controller inhibited
Blinking quickly
Off
Undervoltage or overvoltage
Blinking slowly
Off
Active fault
