Technical data
Protective insulation
4
EDK82ZAFCC-200 DE/EN/FR 4.0
45

H2 Schutzisolierung-INS_Klembesch
Protective insulation
Insulation between bus and ... Type of insulation (in accordance with
EN 61800-5-1)
Power section
– 8200 vector Reinforced insulation
– 8200 motec Reinforced insulation
Reference earth / PE (X3/7) Functional insulation
Supply for CINH (X3/20) Functional insulation
Controller inhibit, CINH (X3/28) Functional insulation
Connection terminals
Terminal
X3/
Designation Function / level
39 GND2 Reference potential 2 of the controller inhibit (CINH) at X3/28
28 CINH Controller inhibit
Input resistance: 3.3 k
Ω
Start = HIGH (+12 ... +30 V DC)
Stop = LOW (0 ... +3 V DC)
Reference: GND2
External supply with U ext = +12 V DC - 0 % ... +30 V DC + 0 %
Internal supply via terminal X3/20
7 GND1 Reference potential 1
LO CAN-LOW CAN data line (LOW)
HI CAN-HIGH CAN data line (HIGH)
E1, E2 Digital inputs User-defined
Input resistance: 3.3 k
Ω
0 = LOW ( 0 ... +3 V) PLC level, HTL
1 = HIGH (+12 ... +30 V) PLC level, HTL
Reference: GND2
E1 can optionally also be used as frequency input (0 ... 10 kHz,
single-track or 0 ... 1 kHz two-track, configuration via C0425).
20 Voltage source for internal supply
U int = +20 V DC
I max = 30 mA
Reference: GND1
