Technical data
Protective insulation
4
l
16 EDS82ZAFPC010 EN 4.0
4.3 Protective insulation
{
Danger!
Dangerous electrical voltage
If Lenze controllers are used on a phase earthed mains with a rated mains
voltage
³ 400 V, protection against accidental contact is not ensured without
implementing external measures.
Possible consequences:
ƒ Death or serious injury
Protective measures:
ƒ If protection against accidental contact is required for the control terminals
of the controller and the connections of the plugged device modules, ...
– a double isolating distance must exist.
– the components to be connected must be provided with the second
isolating distance.
E82ZAFPC001function module
Protective insulation between bus and ... Type of insulation (according to EN 61800−5−1)
l Power section
– 8200 vector Reinforced insulation
– 8200 motec Reinforced insulation
– starttec Reinforced insulation
l Reference earth / PE (X3/7) Functional insulation
l External supply (X3/59) Functional insulation
l Terminal X3/20 Functional insulation
l Terminal X3/28 Functional insulation
E82ZAFPC010 function module
Insulation between bus and ... Type of insulation (in accordance with EN 61800−5−1)
l 8200 vector power stage Reinforced insulation
l Reference earth / PE (X3.2/7, X3.3/7) Functional insulation
l External supply (X3.2/59) Functional insulation
l Supply for CINH (X3.3/20) Functional insulation
l Controller inhibit, CINH (X3.3/28) Functional insulation
