Commissioning
Setting the bus device address
7
EDK82ZAFPC-201 DE/EN/FR 6.0
75

H2_Teilnehmeradresse_einstellen-Schalter_Adresse_einst_TAB
Setting the bus device address
The bus device address can be set with the DIP switches S1 ... S7 () or via code C1509.

Note!
ƒ The bus device addresses of networked controllers must differ from each
other.
ƒ If the DIP switches S1 ... S7 are in the OFF position, the code setting for the
bus device address is active.
ƒ Switch off the voltage supply of the function module and the controller,
and then switch it on again to activate changed settings.
Valid address range
Input via Valid address range Notes
Operating module or
»GDC« 3 ... 126 -
DIP switches 3 ... 125 If the addresses 0, 1, 2, 126 or 127 are set,
the settings from code C1509 become active.
Setting via code
ƒ DIP switches S1 ... S7 = OFF (Lenze setting)
ƒ Set the bus device address via C1509.
