2 BA 12.0032-EN 2.0
Product key
Gearbox
type
Gearbox
size
Stage
number
Input design Output design Drive size
Bevel gearbox
with clutch
Solid shaft
Without foot mounting
with centering
M
G K K V R
Three-phase
motor
C
l with circular flange
(threaded holes)
with square flange
(through holes)
without flange
N
Example motor
Example
bearing flange / free input shaft
0 7 1 C 3 2
1 C
A Foot-mounting with
centring
GKK mounting positions
A B
C D
Additions / changes to the Operating Instructions
Material number Edition Important Contents
13017201 1.0 08/2004 TD09 1st edition First printing
13057302 2.0 06/2005 TD09 2nd edition
replaces 13017201
Revision of sections Mounting positions, Transport weights,
Breather position and Lubricant tables
