Technical data
Characteristics for light load application
3
11 BA 12.0032-EN 2.0
3 Technical data
ƒ The most important technical data are indicated on the nameplate (for Design and
Contents see page 3).
ƒ Additional technical data are listed in the product catalogues.
The output torque and radial forces are rated data and dependent upon:
ƒ
Speed
ƒ Mounting position
ƒ Ambient temperature
ƒ Ratio
ƒ Motor power
ƒ Application of force of radial load
Depending on the application, the permissible load can be reduced.
Stop!
The MOC geared motors GKK are classified as light load or heavy load; see the
characteristics in the following tables .
3.1 Characteristics for light load application
Gearbox type Max. torque Max. radial force Driven shafts Ratios Speed variants yp
[ Nm ] [N] d x l [mm] [i]
p
GKK 04-2M... 70 5600 20 x 35
7.72
15.16
19.52
40.84
FU
GKK 05-2M... 160 8000 25 x 35
12.38
19.74
24.56
38.57
FU
