Technical data
General data
4
EDK94AYCDN DE/EN/FR/ES/IT 3.0 33
l
H1_Daten−GHB Servo Drives 9400
4 Technical data
General data
Field Values
Order designation E94AYCDN
Communication profile DeviceNet
Interface 5−pole plug connector with screw connection
Communication medium EN 11898
Network topology Line terminated at both ends (R = 120
W
)
Number of DeviceNet nodes Max. 64
Max. cable length 500 m (depending on the baud rate selected and the cable type
used)
DeviceNet node Slave
Vendor ID 445 dec (1BD hex )
Type 0 (generic device)
Product code 9400 dec (24BB8 ex )
Baud rate 125, 250, 500 kbps (adjustable via DIP switches)
Voltage supply External supply via the 5−pole plug connector
l "V+": U = 24 V DC, I max = 170 mA
l "V−": reference potential for external voltage supply
Conformities, approvals l CE
l UL
,
"Servo Drives 9400" hardware manual
Here you can find the ambient conditions and the electromagnetic
compatibility (EMC) specifications applying to the communication module.
