Leica M series User Manual 20
Tools used
★ None
Assembling the Optics Carrier
1. Unscrew the clamping screw on the holder
for the optics carrier.
2. Place the optics carrier into the holder and
align it in such a way that the notch in the
optics carrier and the bottom clamping
screw are on top of each other.
2. Tighten the clamping screw below the
optics carrier.
Optics Carrier
