Instruction manual V2.1 – 03/2004 8
5.1 Leica SM2000 R - Overview
Parts list
1 Section thickness adjusting knob
2 Coarse feed wheel
3 Manual feed
4 Mount for specimen clamp
5 Specimen cylinder
6 Universal cassette clamp
6a 2 attachment screws (universal cassette clamp) - see Fig. 13.1
7 Standard specimen clamp
7a 4 attachment screws (standard specimen clamp) - see Fig. 13.1
8 Locking lever for specimen orientation
9 Adjusting screw for specimen orientation - x-axis
10 Adjusting screw for specimen orientation - y-axis
11 Knife sledge
12 Grip for knife sledge movement
13 Knife holder
14 Knife guard
15 Disposable blade holder (optional accessory)
16 Knife clamping screw
17 Clamping lever for knife holder
18 4 holes in the knife sledge for mounting the knife holder (covered by the knife holder
in Fig. 7.1 and 7.2, see Fig 12.1)
19 Clamping screw for clearance angle adjustment
20 Adjusting lever for clearance angle
21 Clearance angle scale
22 Adjusting knob for automatic feed
23 Locking screw for knife sledge
24 Magnetic knife sledge immobilizer
25 Height adjustment screws
26 Section waste tray (optional accessory)
27 Distance plate for knife holder (optional accessory, Fig. 18.2)
5. General description
