Leica Printer IP C/S
Key Instructions V 2.0 - 08/2013
• Open the red protective cap (5,
Fig. 4
) one
turn counterclockwise.
• Then fully insert the ink cartridge into
the slot.
Puncturing the cartridge seal
requires that some force be
applied. Withdraw the ink car-
tridge about 30 mm from the slot
and push it back in as far as it
will go; repeat this step two or
three times (6,
Fig. 4
).
6
6
7
Removing the red protective cap
• Unscrew the red protective cap all the
way, remove the information flag and
place the red protective cap in the recess
provided on the ink cartridge (6,
Fig. 5
).
• Upon completion, make sure that the ink
cartridge is secured by the red retaining
bracket (7,
Fig. 5
) and close the door on
the printer.
Fig. 4
Fig. 5
Follow the information on the
flag attached to the ink car-
tridge.
Informational flag
