Koolance VID-290 User Manual
Page 2

3
Place the Koolance block over the video card
and tighten each screw on the reverse side
of the card.
The Koolance VID-290 cooler is mounted
using the original video card’s heat sink
screws, rentention bracket, and back plate.
NOTE: Not all original screws will be needed
to mount the water block.
Connecting VID-290 Coolers in CrossFire
When connecting VID-290 coolers in series (such as in CrossFire), Koolance offers
an optional direct-connect nozzle. This minimizes liquid routing while avoiding
potential confl icts with hardware in between the video cards.
Optional Two Slot Dual Video Connector
(Koolance CNT-VD2)
Optional Four Slot Dual Video Connector
(Koolance CNT-VD4)
4
The Koolance VID-290 cool includes redundant G1/4 threading on both sides. This
means the input/output nozzles can be placed on either side of the cooler.
Two G1/4 “caps” are included
with Koolance VID-series
coolers which can be placed
opposite the desired nozzle
locations.
3
Place the Koolance block over the video card
and tighten each screw on the reverse side
of the card.
The Koolance VID-290 cooler is mounted
using the original video card’s heat sink
screws, rentention bracket, and back plate.
NOTE: Not all original screws will be needed
to mount the water block.
Connecting VID-290 Coolers in CrossFire
When connecting VID-290 coolers in series (such as in CrossFire), Koolance offers
an optional direct-connect nozzle. This minimizes liquid routing while avoiding
potential confl icts with hardware in between the video cards.
Optional Two Slot Dual Video Connector
(Koolance CNT-VD2)
Optional Four Slot Dual Video Connector
(Koolance CNT-VD4)
4
The Koolance VID-290 cool includes redundant G1/4 threading on both sides. This
means the input/output nozzles can be placed on either side of the cooler.
Two G1/4 “caps” are included
with Koolance VID-series
coolers which can be placed
opposite the desired nozzle
locations.
