14

PERFORMANCE OPTIONS:


Once the input parameters for the wheel diameter and the loaded weight are entered, the Display is able
to show following: Speed & instantaneous Horsepower output of the driven wheel. Maximum HP and 0
to 60MPH times are captured in background.







Push ‘Mode’ button to scroll through different screens.

ƒ

1

st

screen in this mode is the speed in MPH or KPH

z

Use it to compare accuracy. Adjust wheel diameter

input to correlate actual rolling diameter of the bike.

ƒ

2

nd

screen in this mode is the instantaneous HP output.

z

HP readings and bar graph will fluctuate continuously

as you accelerate or slow down.


ƒ

3

rd

screen in this mode is for 0 to 60 MPH capture time.

z

When the horizontal bar graph is full – time is shown.

You can review this reading even after pulling over.
The best effort readings overwrite previous ones.

ƒ

4

th

screen in this mode is for Max HP achieved.

z

Horizontal bar graph is blanked out to distinguish it from

the real-time HP display. You can review this reading

even after pulling over. Maximum values are shown.

REQUIRED SETUP

n

Push & Hold both tire

buttons, Display will show
rear tire icon and either
MPH or KPH will come on.

o

Push & hold rear tire

button to advance the rear
wheel diameters from 10”
to 20” to match your
wheel.

p

Push the ‘Mode’ Button

to register the new value.

q

Push & Hold the front

tire button to advance the
total loaded weight of the
bike (including you) from
500 to 1750 lbs or 250 to
900 Kg.

r

Push the ‘Mode’ Button

to register the new value.

ƒ

To enter Performance monitoring Mode

ƒ

Push & Hold both tire buttons until the 1

st

screen shows.
