a)
DOSIDIS
On
off
CYCLE
PAUSE
EASYDIS
CYCLE CYCLE
PAUSE PAUSE
ON ON
OFF OFF
- Evacuation
of water
Fig. 14 Fig. 14
- Unwinding
b)
c)
d)
- Wheels chain
clutchs
OPERATION
User instruction book St8
Unwinding PE hose
4)
Disengage Disengage
- It is necessary to prepare the hosereel
before unwinding:
1 - Verify that the 2 clutchs
is disengaged
- Disengage
the clutch:
IMPORTANT: IMPORTANT:
It’s imperative then the clutch are engage or disengage on 2 side
in even time to maintain the synchronization of mechanism
- Anti-return
pawl
Anti-return pawl upper Anti-return pawl upper
2 - Raise the
anti-return pawl
DO NOT PARK IN FRONT OR BEHIND
THE DRUM DURING UNWINDING
DO NOT TO UNWIND HOSE WITH A TRACTOR THAT DOESN'T HAVE THE SUFFICIENT WEIGHT TO OVERCOME
THE ADHESION THAT THE LAND GENERATES ON THE TUBE. THE STABILIZER LEGS WON'T BE ABLE TO
TO FILL THEIR ROLE IF THE WHEELS OF THE REEL ARE NOT, MORE OR LESS, PERPENDICULAR TO THE TROLLEY.
It is recommended to till or mow vegetation if the tube adhesion is very high
soil. (Ex: pea, soy or beets ...)
Water always remains in the PE hose, therefore it is preferable during unwinding to evacuate water
in a nearly channel with the inlet hose.
- La ESC
Electronic speed
control
Push ON
3 - Push on the electronic speed
control (ESC)
- To allow this one to count the length
unwound.
Page 08
