a)
4
Fig. 11 Fig. 11
With the hydraulic lever
revolve the turret until the
trolley is in direction of the row
that you want to irrigate.
1
3
- If unwinding from behind:
after plant the leg in soil.
With the hydraulic lever lower
the jack, in order to put back the
hosereel in horizontal position
3
4
- Use of the
jack for
to increase
the anchorage
b)
3
4
1
2
When unwinding
from behind
OPERATION
User instruction book St3
3)
Position & set up
- 1) Place the hosereel on the side of
the land that you want to irrigate
.
Attention, make sure that the drum
is aligned with the trolley and the
row to irrigate
For a good
positioning
- Well to fix
the hosereel
- Plant the legs
of stabilization.
- On the St8 a watering out of 260° maybe done. It is preferable to have the wheels to 90° in relation to the
wheels of the trolley for a better stabilization.
- With the lever to lower the
legs, to really plant the,
feet in soil until
the hosereel topples slightly
forward
- Supervise the stability of the anchorage especially in the first meters at the time of the winding, the moment,
or the effort of traction is the strongest. In the case or the hosereel gives signs of slip, to stop,
the winding and to drive more the feet in soil.
