Kargo Master Transit Connect/Nv200 Wire Partition (40668) - Manual (Page 2)

Tools Needed Installation Kit
8' Tape Measure (e)
1/4" Socket 1/4" End Wrench Qty 4 -
5/16" Socket 5/16" End Wrench 5/16" -20 x 0.75" L Carriage Bolt
(f)
Qty 6 -
Hardware Pack 3/8" x 1" OD Nylon Spacer
(a) (g)
Qty 12 - Qty 8 -
1/4" - 20 x 0.75" Botton Head Bolt 5/16" Flat Washer
(b) (h)
Qty 20 - Qty 4 -
1/4" Nylock Nut 5/16" Nylock Nut
(c) (i)
Qty 20 - Qty 4 -
1/4" Flat Washer 5/16" Lock Washer
(d) (j)
Qty 8 - Qty 4 -
1/4"-20 x 0.75" L Carriage Bolt M8 x 45mm Hex Head Bolt
(k)
Qty 4 -
Hex Head Screw
5/16" - 20 x 1.375"
(l)
Qty 4 -
Hex head self Threading Screw
5/16" - 20 x 0.75"
For TECHNICAL SUPPORT Call: 800-343-7486 Monday - Friday 7:00 A.M. to 4:00 P.M (PST)
40668 Harware List
Philp Head Screw Driver
